Dahua IPC-HDBW5459E1-ZE-IL - 4MP Motorized 2.8-12mm Wizmind Camera

Dahua IPC-HDBW5459E1-ZE-IL 4MP Motorized 2.8-12mm Wizmind Camera

Optics and image performance

The camera is equipped with a motorized lens from 2.8 to 12 mm allowing precise adjustment of the focal length from a distance to optimize the framing according to the scene to be monitored. It incorporates a 1/1.8" CMOS sensor offering high sensitivity and detailed reproduction, with a maximum resolution of 4 MP in 2688 x 1520 pixels. Advanced image enhancement features include a rotation mode to suit particular installations, 140 dB WDR to handle high light contrasts, 3D NR noise reduction to limit low-light noise, and HLC and BLC to correct backlighting and harsh light sources. A digital watermarking secures the integrity of video streams.

Night Vision & Lighting

The camera features a smart dual light combining infrared and warm light to dynamically adjust the lighting according to the conditions of the scene. The infrared illumination distance reaches 60 meters, while the warm light covers up to 50 meters, allowing for more accurate identification of color details when needed. The minimum illumination reaches 0.0007 Lux at F1.8 in color and 0.0004 Lux at F1.8 in black and white, ensuring usable image capture in extremely low-light environments.

Mechanical movements and coverage angles

The camera head offers a pan range of 0° to 355°, tilt of 0° to 80° and rotation of 0° to 355°, which allows for very flexible positioning to precisely cover the area to be monitored. The horizontal angle of view varies from 115° to 47° depending on the focal length selected, the vertical angle from 62° to 27° and the diagonal angle from 137° to 54°, ensuring both wide coverage and tight framing for monitoring specific points.

Video Performance and Compression

The camera delivers a video stream of up to 25/30 fps in 4 MP (2688 x 1520), ensuring smooth and detailed visualization of scenes. It supports multiple compression formats, including H.265, H.264, H.264H, H.264B, and MJPEG, allowing for the trade-off between image quality, bandwidth, and storage capacity. These codecs ensure easy integration into diverse network architectures and facilitate long-term recording without excessive loss of quality.

Artificial Intelligence and Video Analytics

The equipment incorporates a deep learning algorithm to provide advanced video analysis functions. It includes support for AcuPick for intelligent search in recordings, video metadata generation, IVS for event detection, face detection, and people counting, among other analytical scenarios. Native intelligent analytics features include line crossing and intrusion into a defined area, enabling accurate security policies and reducing false alarms.

Audio, I/O and local storage

The camera has a built-in microphone that allows ambient audio to be captured directly from the device. It has configurable alarm inputs and outputs (2 inputs and 1 output) for integration with other security devices, as well as audio inputs and outputs (1:1) for connecting external microphones or speakers. A micro SD card slot is built-in, with a maximum supported capacity of 1TB, allowing local video recording and data redundancy in addition to a network recorder.

Power and network connectivity

The camera supports multiple power modes, including 12V DC, PoE Plus, and ePoE, providing installation flexibility and reducing the need for additional cabling. The maximum power consumption is 3.7 W in standard operation and can be as high as 5 W depending on the features enabled, which remains optimized for continuous use. ONVIF compatibility (S, G, T, M profiles) and CGI support ensure easy integration into multi-vendor video surveillance systems and various software platforms.

Robustness, environment and dimensions

The enclosure has an IP67 rating for resistance to dust and heavy water splashes, as well as an IK10 certification for high resistance to shocks and vandalism. The camera operates in an extended temperature range of -40°C to 60°C, allowing it to be deployed in demanding outdoor environments. Its dimensions are 11.8 cm high with a diameter of 15.9 cm, and its weight is 1.16 kg, making it a compact and robust device suitable for many installation configurations.

Features Dahua IPC-HDBW5459E1-ZE-IL - 4MP Motorized 2.8-12mm Dual Light Camera:
