Cooper 762REUR-00 868 Mhz 2-Channel Radio Receiver

The 703REUR-00 is a 2-channel fixed receiver.

The 762r is a 2 channel receiver operating on the 868 MHz frequency and can be used with the full range of 868 MHz transmitters

currently offered by Scantronic.

It can be used either as stand-alone equipment or as a radio interface for a wired alarm centre.

Each channel can handle up to 4 separate transmitters of the same type, so a single 762r can be used with up to 8 transmitters.

In addition, the 762r allows you to program different operating modes for the different channels, it is not mandatory to select the same mode for the 2 channels. When learning a transmitter, the 762r assigns it the default operating mode.

The 762r normally operates with an internal antenna but, if required, it can be fitted with an external antenna.

Cooper 762REUR-00 radio transmitter features:

• Scantronic 2-channel receiver in plastic housing 868 MHz

• Freely programmable as 2 x 1 channel or 1 x 2 channel

• Suitable for all Scantronic 700 series transmitters

• Reset manually or from the control panel

• Internal antenna and connection for external antenna (BNC) included

• Outputs: 3 relays (A and B) and low battery notification

• Power supply: 12 Vdc

• Size: 153x110x30mm
