Hikvision DS-KD8003-IME2 two-wire IP intercom module

HIKVISION two-wire IP video intercom station with 2MP fisheye camera

• Physical button Access control function

• It incorporates a microphone and a speaker

• BLC, DNR, true WDR, video sensor

• Two-wire network interface

• RS485 for connecting submodules

• 4 alarm inputs

• IP65 24V DC / 12V DC

• Power Out

Hikvision DS-KD8003-IME2 two-wire IP intercom module features:

Two-pin cable for power and network access

• Access control function

• Noise suppression and echo cancellation

• H.264 video compression

• low lighting

• Tamper alarm

• Fisheye camera with additional infrared illumination

• Supports access to up to 8 submodules

• Customizing name tags

• Easy to extend

• Technical specifications

• Built-in microprocessor

• Embedded Linux operating system

• Mode of operation by physical button

• 2-megapixel low-light camera with infrared illumination

• H.264 video compression

• Main stream resolution: 1080P (1920x1080)

• Sub Stream Resolution: 720x480

• BLC backlight compensation

• Real wdr

• DNR digital noise reduction

• Video sensor

• 50/60Hz anti-flicker

• Viewing Angle: 180°(H), 96°(V)

• Full-duplex two-way audio

• It incorporates an omnidirectional microphone

• Includes loudspeaker (> 80 dB at 20 cm)

• G.711U audio compression

• 64Kbps audio compression rate

• Noise suppression and echo cancellation

• Wired network interface with two-wire transmission

• Protocols: TCP/IP, RSTP

• Relay interface (main module): 2, NC + NA extracted separately

• RS485 port for connection between modules

• Tamper alarm

• 4 alarm inputs

• Power supply: 24V DC (two-wire power supply), 12V DC (independent power supply)

• Consumption: 16W~20W

• Output power: 12V DC (only to power sub-modules)

• -40°C ~ +60°C operating temperature

• Operating humidity of 10%~95%

• Degree of protection IP65

• Dimensions: 99.8 (W) x 98 (H) x 43.9mm

• Weight: 375g
