LiXee ZLinky_TIC - ICT to Zigbee 3.0 interface for Linky meter

The ZLinky_TIC module transmits the data from your Linky meter via ZigBee 3.0, offering extensive compatibility with home automation boxes and complete management of historical and standard modes.

Strengths:

• ZigBee 3.0 compatibility: Works with all compatible home automation boxes, such as Jeedom, Home Assistant and Domoticz.

• Simplified installation: Self-powered by the Linky meter, no cables or external sources needed.

• Advanced Data Management: Supports BASE, HCHP, Tempo modes in single or three-phase, providing a flexible solution for home and growers.

The LiXee ZLinky_TIC module is an ideal solution for connecting your Linky meter to your home automation ecosystem thanks to ZigBee 3.0 technology. Compact and lightweight, this device connects directly to the teleinformation terminals of your Linky meter, simplifying installation and eliminating the need for an external power supply.

ZLinky_TIC supports historical and standard modes, suitable for BASE, HCHP (Off-peak/Peak Hours) and Tempo subscriptions, in both single and three-phase. It can be easily integrated into your home automation system by communicating with compatible boxes such as Domoticz, Jeedom, Home Assistant or Eedomus.

However, it is important to note some compatibility restrictions. The module does not work with the Linky meters of the ISKRA ITRON and LANDYS GYR brands with a USB port, as these models only have two pins for teleinformation. In addition, the Linky meter does not report injection data in standard EAIT mode for photovoltaic installations under CACSI contract.

With a robust design and an operating temperature range from 0°C to 60°C, ZLinky_TIC is a reliable and high-performance module to optimize your energy management while integrating seamlessly with your existing home automation solutions.

Installation of the linky meter module:

Follow these instructions:

Remove the green cover from the Linky meter

Insert the Zliky_TIC module by pressing the button above.

Technical characteristics:

• Dimensions: 63 x 24 x 16 mm
• Weight: 15 g
• Feeding: Self-powered by the Linky meter
• Communication: ZigBee 3.0 (2.4 GHz)
• Compatibility:
  • Coordinators: All ZigBee 3.0 compatible coordinators
  • Home automation box: Domoticz, Jeedom, Home Assistant, Eedomus
• Supported Modes: Historical, Standard
• Compatible subscriptions: BASE, HCHP, Tempo, Single or Three Phase
• Operating temperature: 0°C to 60°C
• Reference: LIXEE-ZLINKY-TIC
• Version: 1.2
