Dahua DH-IPC-HFW3549T1-AS-PV-0280B-S5 - 5 Megapixel IP CCTV Camera Eyeball Integrated Siren

The Dahua DH-IPC-HFW3549T1-AS-PV-0280B-S5 camera is an IP video surveillance camera with a resolution of 5 megapixels. It is designed in an eyeball form, which allows flexibility in the orientation of the camera. In addition, it is equipped with a built-in siren, which can be useful for deterring intruders or alerting if suspicious movements are detected.

This camera is ideal for monitoring sensitive areas such as building entrances, parking lots, warehouses, and residential areas, providing enhanced security with its advanced detection and deterrence features.

Dahua DH-IPC-HFW3549T1-AS-PV-0280B-S5 CCTV camera is an advanced IP solution from the WizSense series, designed for effective outdoor surveillance, even in low-light conditions.

• Resolution: 5 megapixels (2592 × 1944)

• Sensor: 1/2.7" CMOS with Full-Color technology for 24/7 color viewing

• Lens: 2.8mm fixed with a 97° horizontal angle of view

• Lighting: Smart dual lighting with infrared LEDs and warm light, range up to 30 meters

• Video compression: AI H.265+, Smart H.265+, H.264, MJPEG

• Wide Dynamic Range (WDR)**: 120 dB for clear images in high-contrast conditions

• Audio: Built-in microphone and speaker for two-way communication

• Storage: Micro SD card slot up to 512GB

• Power supply: 12V DC or PoE (802.3af)

• Protection: IP67 rating against dust and water

• Smart features

Intelligent detection: intrusion and lane departure detection with people and vehicle classification

SMD 4.0: Reducing false alarms with accurate motion detection

Active deterrence: audible alarm and red and blue light flash in case of detected event

Anomaly detection: motion detection, video sabotage, scene switching, audio detection, missing or error SD card, network disconnection, IP conflict, illegal access, and voltage detection

Recommended Applications

This camera is ideal for monitoring sensitive areas such as building entrances, parking lots, warehouses, and residential areas, providing enhanced security with its advanced detection and deterrence features.

Features of Dahua DH-IPC-HFW3549T1-AS-PV-0280B-S5 IP CCTV Camera 5 Megapixel Eyeball Siren Built-in:

• Motorized Lens: 2.7-13.5mm (-Z)

• 1/2.7'' CMOS sensor

• Maximum resolution: 5MP

• Infrared distance: 50 meters

• Warm light distance: 40 meters

• 2x IR LEDs, 2x warm light

• Image enhancement function: Rotation mode, WDR(120dB), 3D NR, HLC, BLC, digital watermark, applicable to various surveillance scenes

• PoE Power Supply (802.3af), DC12V, max. 9.2W, max. 7.9W

• IP67

• 20fps@5MP(2960x1668)

• H.265/H.264/H.264H/H.264B/MJPEG Video Compression

• Intelligent analysis function: line crossing, zone intrusion

• SMD 4.0, AI SSA

• Minimum illumination 0.003 Lux@F1.0 (Color, 30IRE) 0.0003 Lux@F1.0 (B&W, 30IRE)

• Pan: 0°~360°, Tilt: 0°~90°, Rotation: 0°~360°

• Angle of view: H: 113-36°, V: 57-20°, D: 137-40°

• SD card slot, max. 512GB

• I/O Alarm 1/1, Audio I/O 1/1

• 3 streams

• Compatibility: ONVIF(Profile S/G/T), CGI

• Operating Temperature -30°C to 60°C

• Dimensions: 28.8cm x 9.4cm x 8.4cm

• Weight: 1.05Kg
